HDPE Sheets & Rods Manufacturers
High Density Polyethylene (HDPE) Rod / Sheet is an FDA-approved material of the highest grade with outstanding impact resistance. HDPE Sheets and Rods has a high tensile strength, a low moisture absorption rate, and is chemical and corrosion resistant. It is a lightweight, non-toxic, and stain-resistant material that is utilised in a wide range of applications and industries.
HDPE materials are available in rod and sheet form. If you have any particular requirements, such as custom cut sizes, special-order colours, fabrication, or machining.
HDPE Sheet and Rod Features:
- Meets FDA/USDA food handling guidelines (Natural white color)
- Light-weight
- Non-Toxic
- Chemical and corrosion resistant
- Low moisture absorption
- High tensile strength
- Excellent impact resistance
General Applications:
- Cutting Boards
- Chemical Tanks
- Light Duty chain guides
- Orthotics and prosthetic device
- Water storage
- Food Processing
- Thermoforming
- Chair and belt guides
- Wear strips, guide rails and neck guides
- Corner tracks
- Spiral Conveyors
- Extruded profiles and guide rails
- Other construction parts and components
HDPE Sheets and Rods Characteristics:
- Very good welding and processing properties
- Excellent impact strength and twisting endurance
- Excellent chemical and corrosion resistance
- Good electrical properties
- Lightweight, no poison
HDPE Sheet & Rod Size for Sheets
| Thickness | Width | Length |
|---|---|---|
| 3mm~250mm | 1000mm~1300mm | Any length |
| Standard size | |
|---|---|
| Thickness | 3mm~12mm |
| 1220mm×2440mm | √ |
| 1500mm×3000mm | |
| 1300mm×2000mm | √ |
| 1000mm×2000mm | √ |
We can also provide any other sizes according to your special needs.
CHART OF PE- HDPE EXTRUDED SQUARE RODS
* Standard Length 1 Meter to 6 Meter
| Sl. No | Size in MM | Size in Inch | POLYPROPYLENE SQUARE Approx. Weight 300 mm Long |
|---|---|---|---|
| 1 | 16.00 x 16.00 | 5/8″ | 0.075 |
| 2 | 20.00 x 20.00 | 3/4″ | 0.121 |
| 3 | 25.40 x 25.40 | 1″ | 0.230 |
| 4 | 31.70 x 31.70 | 1 1/4″ | 0.375 |
| 5 | 38.10 x 38.10 | 1 1/2″ | 0.500 |
| 6 | 50.80 x 50.80 | 2″ | 0.840 |
| 7 | 63.50 x 63.50 | 2 1/2″ | 1.300 |
| 8 | 76.20 x 76.20 | 3″ | 1.790 |
| 9 | 100.00 x 100.00 | 4″ | 2.860 |
| 10 | 125 x 125 | 5″ | 51100 |
| PROFILES PRODUCT RANGE | |
|---|---|
| 15X22 | 35X23 |
| 15X40 | 35X35 |
| 25X35 | 45X55 |
| 25X45 | 50X40 |
| 20X40 | 60X40 |
| 30X40 | 60X50 |
| 30X45 | 85X25 |
| 25X50 | 88X35 |
| 30X50 | 100X62 |
HDPE Sheets and Rods Weight Chart for Rods
| Dia in MM | APPROX.WT.IN.KG/ FOOT | Approx. wt. in Kg / Mtr |
|---|---|---|
| 16 | 0.06 | 0.2 |
| 20 | 0.1 | 0.32 |
| 22 | 0.12 | 0.37 |
| 25 | 0.15 | 0.51 |
| 30 | 0.22 | 0.72 |
| 32 | 0.25 | 0.82 |
| 35 | 0.29 | 0.97 |
| 40 | 0.38 | 1.25 |
| 42 | 0.42 | 1.38 |
| 45 | 0.48 | 1.58 |
| 50 | 0.58 | 1.93 |
| 60 | 0.84 | 2.77 |
| 65 | 0.99 | 3.25 |
| 70 | 1.15 | 3.76 |
| 75 | 1.31 | 4.3 |
| 80 | 1.52 | 5.01 |
| 85 | 1.68 | 5.52 |
| 90 | 1.88 | 6.18 |
| 95 | 2.09 | 6.88 |
| 100 | 2.36 | 7.75 |
| 110 | 2.8 | 9.2 |
| 115 | 3.06 | 10.05 |
| 120 | 3.38 | 11.09 |
| 125 | 3.61 | 11.85 |
| 130 | 3.96 | 13 |
| 140 | 4.62 | 15.18 |
| 150 | 5.18 | 17 |
| 165 | 6.34 | 20.8 |
| 180 | 7.62 | 25 |
| 205 | 9.85 | 32.3 |
| 230 | 12.35 | 40.5 |
| 260 | 15.73 | 51.5 |
| 280 | 18.44 | 60.5 |
| 300 | 21.34 | 70 |
| 350 | 28.65 | 94 |
HDPE Sheets and Rods Application
Construction materials for chemical, mechanical, package and electronic industry, eg. tanks, Lab equipment, Etching equipment, Semiconductor processing equipment, machined parts industrial doors, and so on.
HDPE Sheets (High-Density Polyethylene)
HDPE (High-Density Polyethylene) Sheets are known for their strength, chemical resistance, and impact resistance. Commonly used in water tanks, cutting boards, liners, and food-grade applications. These sheets are lightweight, non-toxic, and highly durable, making them ideal for both industrial and commercial use. HDPE’s low moisture absorption and excellent corrosion resistance ensure long-term performance, even in harsh environments. Whether it’s for hygienic surfaces in food processing or structural components in construction, HDPE sheets deliver reliable and cost-effective solutions.
HDPE Sheets Technical Information
| Property | Specification |
| Density | ~0.96 g/cm³ |
| Tensile Strength | ~25 MPa |
| Temperature Resistance | Up to 100°C |
| UV Resistance | Good (in black grade) |
| Food Grade | Available |
